Quantum Fusion E Rear Wheel Drive Powerchair

The Fusion E is a cost-effective power chair that combines a modular, state-of-the-art design with exceptional performance. It features enhanced obstacle climbing capabilities and a smooth ride, making it suitable for even the most active users. With its advanced features and sleek design, the Fusion E is a reliable and versatile choice.

Key Features:

1. Lights & Indicators (6mph): The Fusion E ensures visibility and safety with its integrated lights and indicators, allowing you to navigate confidently in various environments.

2. Solid or Pneumatic Tyre Options: Choose between solid or pneumatic tyres based on your preferences and specific needs. Both options provide reliable traction and durability.

3. Rear Suspension: Experience a smoother ride and improved comfort with the Fusion E's independent rear suspension, which absorbs shocks and vibrations for enhanced stability.

4. VR2 Controls: The Fusion E is equipped with user-friendly VR2 controls, offering intuitive operation and customizable settings for a personalized driving experience.

Specifications:

• Weight Capacity: Up to 23 stone 6 lbs (150 kg)
• Overall Product Weight: 211.64 lbs (96 kg)
• Maximum Speed: Choose between 4 mph and 6 mph options
• Ground Clearance: 40 mm (1.57") at the lowest point of the frame
• Turning Radius: 641.5 mm (25.25")
• Overall Size:
  • Length: 1050 mm (41.33") with Front Riggings
  • Width: 630 mm (24.8")
• Maximum Obstacle Climbing Ability: 100 mm (3.94")
• Seat Sizes: Available from 15"W x 15"D to 22"W x 23"D
• Angle Adjustable Backrest: Choose from 5°, 15°, 25°, or 35° for personalized comfort

Wheels and Drivetrain:

• Drive Wheels: 355 mm (14") solid/pneumatic wheels with rear-wheel drive for excellent traction
• Caster Wheels: 254 mm (10") pneumatic wheels for maneuverability
• Anti-Tip Wheels: 50.8 mm (2") anti-tip wheels for added stability
• Suspension: Independent rear suspension for a smoother ride
• Drivetrain: Two 350w motors for powerful rear-wheel drive performance
• Brakes: Auto magnetic brakes for reliable stopping power

Battery and Charger:

• Batteries: Two 40 Ah deep cycle batteries for long-lasting power
• Battery Charger: 5-Amp off-board charger for convenient recharging

Other Features:

• Versatile Design: The Fusion E features an easily adjustable seat to accommodate growth and provide long-term usability.
• Swing-Away Legrests: Enjoy added comfort and convenience with swing-away legrests.
• Height Adjustable Armrests: Customize the armrest height to suit your preferences and ensure optimal support.

Color Option:

• Black

For more information and a full range of available options, please contact Millercare on 0800 652 8533
