Quantum 4Front 2 HD Powerchair

Introducing the 4Front® 2 HD Powerchair: Enhanced Heavy Duty Performance

Experience the future of powerchairs with the 4Front® 2 HD, a cutting-edge model that combines advanced features and heavy-duty capabilities. Equipped with two 73 Ah batteries as standard, this powerchair ensures reliable and long-lasting power for your mobility needs.

With its 10" lift, the 4Front® 2 HD can effortlessly handle weights up to an impressive 28 st 8 lbs. Whether you prefer a flat-free or pneumatic 14" (356 mm) wheel, the choice is yours, offering flexibility to match your preferences and terrain requirements.

Unleash the power of the 4Front® 2 HD, boasting a remarkable weight capacity of up to 32 st 2 lbs (204 kg). This powerchair guarantees stability and durability, enabling you to navigate various environments with confidence.

Enhanced Features for Unmatched Performance

Experience unrivaled driving performance with the 4Front® 2 HD's latest Smart Traction Control (STC) and Smooth Ride Suspension (SRS) technologies. These innovative features ensure stability during obstacle transitions, providing a smooth and seamless ride every time.

Discover the Next Generation of Powerchair Excellence

For the ultimate in powerchair performance, look no further than the 4Front® 2 HD. Its state-of-the-art design and heavy-duty capabilities make it the perfect choice for individuals seeking top-notch mobility solutions.

To learn more about the 4Front® 2 HD and explore the full range of options and colors available, please give Millercare a call on 0800 652 8533

Specifications at a Glance:

• Power Chair Weight Capacity: 32 st 2 lbs (204 kg)
• Weight Capacity with 10" lift: 28 st 8 lbs (181 kg)
• Maximum Speed: Up to 4 mph (6.4 km/h) or up to 2.7 mph (4.3 km/h) with 10" lift
• Ground Clearance: 80 mm (3.15") at battery tray
• Turning Radius: 623 mm (24.5")
• Overall Size:
• Length: 1168 mm (45.9")
• Width: 618 mm (24.3")
• Component Weights:
• Base: 63.5 kg (140 lbs)
• Batteries (standard): 23.36 kg (51.5 lbs) each
• Wheels:
• Drive Wheels: Standard 356 mm (14") flat-free
• Caster Wheels: Rear 229 mm (9") flat-free
• Anti-Tip Wheels: Front 102 mm (4") flat-free
• Suspension: Smooth Ride Suspension (SRS)
• Batteries:
• 2 x 73 Ah batteries (standard)
• Battery Charger: 8-amp, off-board
• Seating Sizes:
• Width: 20" - 24"
• Depth: 20" - 24"

Available Options:

• 10" power adjustable safe seat elevation (speeds up to 3.5 mph)
• USB Mobile Device Charger (specify fitting location: left armrest or seat rail)
• Cup Holder (only available with TB3 Flip-up armrests)
• Personal Item Hook (not available with Back Cane Option)
• Reflector Kit
• Mobile Phone/Media Holder (only available with TB3 Flip-up armrests)
• Backpack Holder (pair) (not available with Back Cane Option)
• Glove Box
• Hydration System
• Oxygen Holder
• Personal Item Hook (not available with Back Cane Option)

Experience the ultimate powerchair revolution with the 4Front® 2 HD. Choose from an array of captivating colors such as Back in Black, Electric Blue, Red Corvette, Pretty in Pink, Grey Street, and White Satin. Contact your representative for the full range of options and colors available.

Product Specifications:

• Model: 4FRONT 2 HD WITH TB3 SEATING
• SRS Suspension System
• Smart Traction Control
• Q-Logic 3e Control System
• 2 x 70 ah Batteries
• 4 Mph (6 Km/h) 4-Pole Motors
• Max User Weight: 32 st 14lbs. (204 kg)
• 14 Colour Options
• Height Adjustable Removable Armrests
• Centre Mount Foot Platform
• TB3 Seating
• 14” Flat Free Drive Tyres
• 2” x 9” Flat Free Rear Castors

Colour Options:

• Midnight Blue
• Electric Blue
• Back in Black
• Green Machine
• Red Corvette
• Pretty in Pink
• Blue Jean
• Deep Purple
• Evolution Orange*
• Military Green*
• Lemon Crush*
• Night Train*
• Grey Street*
• Raspberry Beret*

Additional Ad-On Options:

• Custom Hydro Dip
• Stealth Seat Cushions: ADI Q-Back 2

Seat Positioning Options:

• Powered Seat Lift & Tilt: 10” lift & 50° tilt
• Static Seat
• TRU-Balance 3 HD Powered Seat Tilt: 0° to 50° COG tilt

Seat Packeges - Seat Width:

• 20”-24”W

Seat Packeges - Seat Depth:

• Set width at: [Enter width]
• Set depth at: [Enter depth]

TB3 Back Support Positioning:

• Tool Angle Adjustable: 85° to 120° in 5° increments

Arm Supports:

• TB3 Flip-back with Down Posts: Adjustment range 8”-16” from seat pan
• Arm Support Pads: 10” Standard

Leg Supports:

• Manually Adjustable Centre Mount Foot Platform
• Lower Leg Extensions: From seat pan - 10”-16”
• Footplates: 10”W x 8”D Split Footplates

Configurable Leg Supports:

• Lower Leg Extensions: From seat pan - 8.5”-12”
• Heavy Duty, Drop-in, Swing-away Leg Supports: 70°

Centre Mounted Leg Supports:

• Power Elevating Articulating Centre Mount Foot Platform

For further information please call Millercare on 0800 652 8533
